Steel Bar Welded Grating for Platform and Floor

Steel Bar Welded Grating for Platform and Floor

Name: Steel Bar Welded Grating for Platform and Floor
Brand: ANPING HUXING WIRE MESH PRODUCTS CO.,LTD
SKU: HXSG02
Availability: InStock
Rating: 5 (1 reviews)

Item No.: HXSG02

Surface: Hot Dipped Galvanized;
Type: Smooth Plain Steel Bars;
Style: Welded by Steel Grating Machine;
Welded Steel Grating Usage for Stair Treads, Walk Way, Platform and Various Floor.

INQUIRY PDF Format

Description

Functional Design for Heavy-Duty Structural Use
This steel bar welded grating is engineered to fulfill the rigorous demands of industrial applications, serving as a reliable surface for platforms, stair treads, and walkways. Its design targets engineers, procurement managers, and fabricators requiring strong industrial grating solutions capable of supporting significant load capacities. The versatility allows custom sizing up to 6000mm, accommodating various construction requirements. This product ensures safety with options for anti-slip surfaces and is suitable for environments where structural integrity and personnel protection are critical.

Precise Engineering with Advanced Material Specifications
Manufactured using smooth plain steel bars and specialized welding machinery, the welded grating panels provide exemplary strength and stability. They feature a hot-dipped galvanized coating to significantly prolong corrosion resistance, advantageous for outdoor and corrosive settings. Available in carbon steel or stainless steel variants (304 and 316 grades), the grating meets varying strength and chemical resistance specifications. Supporting bar sizes range from 25x3 mm to 70x5 mm, with cross bars of 6 or 8 mm in diameter, ensuring custom load-bearing configurations by selecting appropriate pitch and material types.

Industrial Applications Enhancing Operational Efficiency
The steel grating panels are widely implemented in sectors such as chemical plants, shipyards, and manufacturing facilities where reliable, durable platform and floor solutions are critical. Their corrosion-resistant finish and strong load capacity facilitate compliance with safety standards, supporting heavy machinery and allowing effective drainage and ventilation. This versatility optimizes workflow by integrating seamlessly into production lines, storage areas, and elevated platforms, contributing to safer and more efficient industrial environments.

Product Advantages

Modular Construction with Enhanced Structural Integrity
The welded grid system employs a rigorous fabrication process using smooth plain steel bars welded at precise intervals to form a high-integrity grid. This steel grating platform design allows modular installation and flexibility in panel sizing, aligning with project-specific dimensional and load-bearing criteria. Hot-dipped galvanization ensures long-term durability against corrosion, reducing maintenance cycles. This level of engineering precision and adaptability distinguishes it within product portfolios offered by leading steel grating suppliers.

Optimized Durability and User Safety Performance
The product’s corrosion-resistant surface combined with customizable sizes offers superior performance in hostile environments, further enhanced by anti-slip treatment options. These panels deliver dependable load capacity and stable footing, critical for minimizing workplace accidents and ensuring continuous operational safety. The ease of installation and maintenance contributes to cost-saving in lifecycle management, offering significant value for industries relying on rugged platform and flooring solutions supplied by a reputable steel grating company.

Steel Bar Welded Grating can be used for Platform and Floor. You can buy and meet open end grating or close end grating according to your requirement. Hot-dipped galvanized finishing is the best anti-corrosion treatment for carbon steel bar grating. Hot dip galvanised is the most widely used steel garting surface. Of course, you can make it with painting. Or we can choose stainless steel 304 materials to produce.

Materials: Carbon Steel, Stainless Steel 304,316;
Surface finishing: Hot Dipped Galvanised.
Weld Steel Grating Panel Sizes: from 200mm to 6000mm.
All Sizes Can be custom-made as your requirement.

Table: Specification of Steel Bar Welded Grating
Item	Specifications of Bearing Bar (mm)	Diameter of Cross Bar (mm)	Pitch of Bearing Bar (mm)	Pitch of Cross Bar (mm)
SG253	25x3	6	20,30,40	50,100
SG254	25x4	6,8	20,30,40	50,100
SG255	25x5	6,8	20,30,40	50,100
SG304	30x4	8	20,30,40	50,100
SG305	30x5	8	20,30,40	50,100
SG355	35x5	8	20,30,40	50,100
SG404	40x4	8	20,30,40	50,100
SG405	40x5	8	20,30,40	50,100
SG455	45x5	8	20,30,40	50,100
SG505	50x5	8	20,30,40	50,100
SG605	60x5	8	30,40	50,100
SG705	70x5	8	30,40	50,100

Use Scenarios

Corrosion-Resistant Flooring for Chemical Processing Plants
Chemical processing facilities require flooring solutions capable of withstanding exposure to aggressive chemicals and frequent moisture. The stainless steel options (304 or 316 grades) within these steel grating panels provide superior resistance to corrosion and chemical degradation, guaranteeing operational longevity. Used as platforms and stair treads, the grating supports strict compliance with industry safety codes and enhances worker security through non-slip surfaces. Integrating seamlessly with plant layouts, these panels facilitate effective drainage and reduce downtime due to corrosion-related repairs.

Heavy-Duty Walkways for Shipyards and Offshore Platforms
In shipyards and offshore environments, exposure to saltwater demands flooring that resists corrosion while providing strong mechanical support. The hot-dipped galvanized finish combined with robust structural design ensures the industrial grating withstands harsh maritime conditions. These walkways maintain stable footing for personnel and equipment access, critical for safe and efficient operations. Their customizable sizes enable straightforward retrofitting in existing infrastructure, contributing to operational continuity and compliance with maritime safety regulations.

FAQ

Can I order custom-sized steel grating panels for specific industrial applications?
Yes, we offer fully customizable steel grating panels ranging from 200mm to 6000mm in size. Our production process allows precise adjustments to meet your platform or flooring project specifications, ensuring the grating fits your installation perfectly.

What types of materials do you provide for your industrial grating products?
We manufacture our industrial grating using carbon steel, stainless steel 304, and stainless steel 316. This variety enables you to select the reliable material based on load requirements and corrosion resistance suitable for your industrial environment.

How do we ensure the steel grating platform withstands harsh outdoor conditions?
Our steel gratings come standard with a hot-dipped galvanized finish, delivering robust corrosion resistance ideal for outdoor or industrial platforms. Additionally, optional surface treatments like painting are available to enhance durability and meet specific environmental needs.

What support do you provide for installation and maintenance of steel bar welded gratings?
We provide detailed technical guidance to assist with proper installation and maintenance to maximize durability and safety. Our team is ready to support your project from specification to delivery, ensuring your steel grating platform performs reliably over time.
